You are here: Home / Products / Silicone LED Strips / Silicone LED Tubes / 6x12mm Flat Curve Neon Tube Sleeve 8mm PCB Silicone Neon LED Diffuser Tube

6x12mm Flat Curve Neon Tube Sleeve 8mm PCB Silicone Neon LED Diffuser Tube


CERTIFICATE:	CE RoHS UKCA ISO CB ETL SAA FCC TUV UL PATENT
Availability:

Quantity:



Inquire Add to Basket

Model: FC0612 | Outer Size: 6mm(W)×12mm(H) | Medium Side-Emitting Silicone Tube

Model:
FW-T-0612

Flat Curve Neon Tube Sleeve 6X12Mm Silicone Led Diffuser Cover 8Mm Pcb Silicone Neon Tube Led Strip Protective Sleeve Flexible Neon Diffuser Tube 6*12Mm Neon Light Cover Silicone Tube For Led Strip Curved Led Neon Sleeve PCB Led Strip Diffuser Cover

Product Description

Core Specifications

Item	Standard Specification
Model Number	FC0612
Outer Dimension	6mm × 12mm (Rectangular Profile)
Inner Dimension	4mm × 10mm (fits 5mm wide bare side-emitting LED strips)
Uniform Wall Thickness	1mm
Silicone Material	Food-grade fumed silica, anti-yellowing formula
Hardness	30±5 Shore A
Waterproof Grade	IP67 (after sealed with matching end caps & silicone glue)
Working Temperature Range	-40℃ ~ +120℃
UV Resistance	Grade 4-5, long-term anti-aging
Light Transmittance	≥90% (high transparent version)
Standard Roll Length	50m/roll, 100m/roll (custom length available)

Key Features

Medium side-emitting profile, specially designed for 5mm wide side-emitting LED strips, provides full IP67 waterproof, dustproof and scratch-resistant protection
Soft and flexible, supports small-radius bending, no cracking or deformation after long-term use
Fully compatible with 6×12mm neon strip mounting clips, aluminum channels and installation accessories
Optimized diffusion structure, uniform light output, no visible LED dots

Optional Types

Type	Core Feature	Application Scenario
High Transparent Version	≥90% light transmittance, minimal brightness loss	Outdoor building contour, landscape side-emitting lighting
Milky White Diffusion Version	Uniform soft glow, no visible LED dots, anti-glare	Indoor commercial, hotel side-emitting lighting
Black Light-Blocking Version	Non-emitting surface light blocking, no stray light	Concealed linear lighting, dark slot installation

Typical Applications

Commercial cabinet, display showcase side-emitting lighting strip protection
Hotel, office building interior side-emitting lighting strip protection
Outdoor building contour, landscape side-emitting strip waterproof upgrade
Ceiling cove, wall outline decorative lighting strip protection

Matching Accessories

IP67 waterproof connectors
FC0612 dedicated waterproof end caps
Food-grade silicone sealant
6mm mounting clips
6×12mm aluminum mounting channels

Detail
